Name: Specifications | microAUDIO 22 / microAUDIO 722 - AUDIO INTERFACE / ANALOGUE FILTER & AUDIO INTERFACE | KORG (Turkey)
Brand: KORG

AUDIO INTERFACE / ANALOGUE FILTER & AUDIO INTERFACE

Audio format: Sampling rate: 44.1 kHz/48 kHz/88.2 kHz/96 kHz/176.4 kHz/192 kHz
Bit rate: 24-bit

Mic input: Dynamic range: 109.5 dB (A characteristic)
THD+N: less than 0.015% (minimum gain, -1 dBFS input)
Maximum input level: -2 dBu (minimum gain)
Gain range: 56 dB Impedance: 1.5 kΩ

Line input: Dynamic range: 109.5 dB (A characteristic)
THD+N: less than 0.004% (minimum gain, -1 dBFS input, 22 Hz/22 kHz bandpass filter)
Maximum input level: 13 dBu/18 dBu (SE/ DIF) (minimum gain) Gain range: 56 dB
Impedance: 1 MΩ/2 MΩ (SE/DIF)

Line output: Dynamic range: 109.5 dB (A characteristic)
THD+N: less than 0.0015% (minimum gain, -1 dBFS input)
Maximum output level: 10 dBu/16 dBu (minimum gain)
Impedance: 330 Ω/660 Ω (SE/DIF)

Headphone output: Dynamic range: 107 dB (A characteristic)
THD+N: less than 0.0015% (minimum gain, -1 dBFS input, 22 Hz/22 kHz bandpass filter)
Maximum output level: 10 dBu (minimum gain)
Impedance: 20 Ω

Jacks and ports: microAUDIO 22: IN 1, 2 jacks (XLR/6.3 mm TRS monaural phone jack), OUT 1, 2 jacks (6.3 mm TRS monaural phone jacks), (USB) port (Type-C), (headphones) jack (6.3 mm stereo phone jack)

microAUDIO 722: IN 1, 2 jacks (XLR/6.3 mm TRS monaural phone jack), OUT 1, 2 jacks (6.3 mm TRS monaural phone jacks), MIDI IN jack, MIDI OUT jack (3.5 mm TRS phone jack), (USB) port (Type-C), (headphones) jack (6.3 mm stereo phone jack)

Dimensions: microAUDIO 22: 150 mm (W) x 128 mm (D) x 68 mm (H)/5.91˝ x 5.04˝ x 2.68˝
microAUDIO 722: 207 mm (W) x 128 mm (D) x 68 mm (H)/8.15˝ x 5.04˝ x 2.68˝

Included items: microAUDIO 22: USB cable, Quick Start Guide
microAUDIO 722: USB cable, MIDI TRS-DIN adapter cables, Quick Start Guide

*	All product names and company names are the trademarks or registered trademarks of their respective owners.
*	Specifications and appearance may be changed without notice for improvement purposes.
